Kuephom PM21

Kuephom Portable CD Player PM21 Instruction Manual

모델: PM21

1. 제품 오버view

The Kuephom Portable CD Player PM21 is a versatile audio device designed for personal and portable use. It features built-in stereo speakers, Bluetooth transmission capabilities, anti-skip protection, and supports various disc formats including CD, MP3, CD-R, and CD-RW. It also includes a USB port for MP3 playback and an AUX output for car or external speaker connection.

Kuephom Portable CD Player with Built-in Stereo Speakers

Image: The Kuephom Portable CD Player, showcasing its compact design and built-in stereo speakers.

패키지 내용:

  • CD 플레이어 x 1
  • 이어 버드 x 1
  • 오디오 케이블 x 1
  • 충전 케이블 x 1
  • 파우치 x 1

2. 설정

장치 충전:

The CD player is equipped with a built-in rechargeable Lithium Ion battery. Before first use, fully charge the device.

  1. Connect the provided charging cable to the player's charging port.
  2. Connect the other end of the charging cable to a compatible USB power source (e.g., wall charger, car charger, power bank, or computer USB port). Note that chargers are not included.
  3. The charging indicator on the LCD screen will show charging status. A full charge typically takes 3-4 hours and provides 5-8 hours of playback time.
Kuephom Portable CD Player charging via USB cable

Image: The CD player connected to a power source via its charging cable, illustrating the rechargeable feature.

Kuephom Portable CD Player showing 'Rechargeable' and 'No Need Batteries' icons

Image: Visual representation highlighting the rechargeable nature of the device, eliminating the need for disposable batteries.

3. 사용 설명서

Basic CD Playback:

  1. CD 수납공간 커버를 엽니다.
  2. Insert a compatible disc (CD, MP3, CD-R, CD-RW) with the label side facing up.
  3. CD 수납공간 커버를 단단히 닫으세요.
  4. 재생을 시작하려면 '재생/일시정지' 버튼을 누르세요.
  5. Adjust volume using the 'Vol+' and 'Vol-' buttons.
  6. Use the 'Previous' and 'Next' buttons to skip tracks.
Kuephom Portable CD Player displaying multi-format disc compatibility

Image: The CD player demonstrating its compatibility with various disc formats including CD, CD-R/RW, MP3/WMA, and audiobooks on CD.

블루투스 전송 :

The player can transmit audio to Bluetooth headphones or speakers.

  1. 블루투스 헤드폰이나 스피커가 페어링 모드인지 확인하세요.
  2. On the CD player, press the 'TRANSMIT' button. The Bluetooth indicator will flash.
  3. The CD player will search for and connect to the nearest discoverable Bluetooth device.
  4. Once connected, the Bluetooth indicator will become solid, and audio will play through the connected device.
Kuephom Portable CD Player transmitting audio to Bluetooth headphones

Image: The CD player actively transmitting audio to Bluetooth headphones, illustrating its wireless capability.

Steps for pairing Kuephom Portable CD Player with a Bluetooth speaker

Image: A four-step guide demonstrating how to pair the CD player with a Bluetooth speaker for audio output.

AUX Car Connection:

Connect the CD player to your car's audio system or other external devices via the 3.5mm AUX jack.

  1. Insert one end of the provided audio cable into the CD player's AUX output jack.
  2. Insert the other end of the audio cable into your car's AUX input jack.
  3. Set your car's audio system to AUX mode.
  4. Adjust the volume on both the CD player and your car's audio system for optimal sound.
Kuephom Portable CD Player connected to a car's AUX input

Image: A step-by-step visual guide showing how to connect the portable CD player to a car's audio system using an AUX cable.

USB 재생 :

The player supports MP3 playback from a USB drive.

  1. MP3가 들어있는 USB 드라이브를 삽입하세요 fileUSB 포트에 s.
  2. The player will automatically switch to USB mode and begin playing MP3 files.
  3. Use the 'Previous', 'Next', and 'Play/Pause' buttons to control playback.

건너뛰기 방지 보호:

The advanced anti-slip and anti-vibration technology ensures uninterrupted playback, even during movement or on bumpy surfaces.

Man walking with backpack containing Kuephom Portable CD Player, highlighting anti-shock protection

Image: A person walking with the CD player in a backpack, illustrating the effectiveness of the anti-shock protection for continuous audio.

Last Playback Memory:

The device automatically recalls the position of the last played track, allowing you to resume listening from where you left off.

4. 유지관리

To ensure the longevity and optimal performance of your Kuephom Portable CD Player, follow these maintenance guidelines:

  • 청소: Use a soft, dry cloth to clean the exterior of the player. For the lens, use a specialized CD lens cleaner if necessary. Avoid using abrasive cleaners or solvents.
  • 디스크 취급 : Always handle discs by their edges. Keep discs clean and free from scratches, dust, and fingerprints. Store discs in their cases when not in use.
  • 저장: Store the player in a cool, dry place away from direct sunlight, extreme temperatures, and high humidity. Use the provided pouch for protection during travel.
  • 배터리 관리 : 배터리 수명을 최적화하려면 배터리를 자주 완전히 방전시키지 마십시오. 장기간 보관할 경우 몇 달에 한 번씩 배터리를 약 50% 정도 충전하십시오.

5. 문제 해결

If you encounter issues with your CD player, refer to the following common solutions:

  • 플레이어가 켜지지 않습니다.
    • Ensure the battery is charged. Connect the player to a power source using the charging cable.
    • 전원 스위치가 'ON' 위치에 있는지 확인하세요.
  • Disc does not play or skips frequently:
    • Verify the disc is clean and free of scratches or smudges. Clean with a soft, lint-free cloth if needed.
    • 디스크의 라벨면이 위를 향하도록 올바르게 삽입되었는지 확인하십시오.
    • Check if the disc format (CD, MP3, CD-R, CD-RW) is supported.
    • For MP3 discs, ensure files are in a compatible format and not corrupted.
  • 소리가 나지 않거나 볼륨이 낮음:
    • Increase the volume on the CD player using the 'Vol+' button.
    • If using headphones, ensure they are properly plugged into the headphone jack.
    • If using Bluetooth, ensure the player is successfully paired and connected to your Bluetooth device, and the volume on the Bluetooth device is also adjusted.
    • If using AUX, ensure the audio cable is securely connected to both the player and the external device, and the external device is set to the correct input.
  • Bluetooth 연결 문제:
    • 블루투스 기기(헤드폰/스피커)가 페어링 모드인지 확인하십시오.
    • Make sure the CD player's 'TRANSMIT' button has been pressed to initiate pairing.
    • Ensure the Bluetooth devices are within close proximity (typically within 10 meters or 33 feet) and free from obstructions.
    • Try turning both devices off and on again, then re-attempt pairing.

이러한 해결 방법을 시도한 후에도 문제가 지속되면 고객 지원팀에 문의하세요.

6. 사양

특징세부 사항
상표쿠에폼
모델 번호오후 21
제품 치수6 x 5 x 1 인치
품목 무게1.06파운드
배터리1개의 리튬 이온 배터리(포함)
연결 기술블루투스, USB, AUX
지원되는 디스크 형식CD, MP3, CD-R, CD-RW
특별 기능Anti-Skip Protection, Battery Level Indicator, Bluetooth Transmission, Rechargeable, Built-in Speakers
제조업체쿠에폼

7. 보증 및 지원

Kuephom is committed to providing quality products. While specific warranty details are not provided in this manual, we encourage you to retain your proof of purchase for any warranty claims. For any operational issues, technical support, or inquiries, please contact Kuephom customer service. We are dedicated to assisting you with any problems you may encounter during use.
