아반트리 오디카스트 3

Avantree Audikast 3 Bluetooth 5.3 Transmitter & TWS116 Open-Ear Wireless Headphones User Manual

Model: Audikast 3 (B0DN62XV35) & TWS116

1. 제품 오버view

This manual provides instructions for setting up and using your Avantree Audikast 3 Bluetooth 5.3 Transmitter and Avantree TWS116 Open-Ear Wireless Headphones. Please read carefully before use.

1.1 Avantree Audikast 3 Bluetooth Transmitter

The Audikast 3 is a Bluetooth 5.3 audio transmitter designed to send audio wirelessly from your TV or other audio sources to Bluetooth headphones or speakers. It features optical and AUX audio input ports, and supports dual link for connecting two pairs of headphones simultaneously.

아반트리 오디카스트 3 블루투스 송신기

Figure 1: Avantree Audikast 3 Transmitter. This image shows the compact black transmitter unit with its various ports and controls.

주요 특징:

  • Bluetooth 5.3 for stable connections.
  • Optical and AUX audio input ports.
  • Dual Link: Connects to two pairs of headphones simultaneously.
  • Qualcomm chipset for clear sound and improved battery life.
  • aptX-Adaptive and Low Latency support for no lip-sync delays.
  • Volume boost for optical connections (up to 6dB).

1.2 Avantree TWS116 Open-Ear Wireless Headphones

The TWS116 headphones feature an open-ear design for comfort and surroundings awareness, making them ideal for active lifestyles. They come with a charging dock for convenience.

아반트리 TWS116 오픈이어 무선 헤드폰

Figure 2: Avantree TWS116 Open-Ear Headphones. This image highlights the comfortable, pressure-free fit of the open-ear design on a user's ear.

주요 특징:

  • Open-ear design for comfort and awareness of surroundings.
  • Pressure-free fit, suitable for glasses and hearing aids.
  • Built-in controls for music and calls.
  • Charging dock for easy recharging.

2. Setup - Audikast 3 Transmitter

2.1 Connecting to Power Source

Connect the Audikast 3 to a power source using the provided USB-C cable. It is recommended to use a TV's USB port so the transmitter powers on/off with your TV.

Video 1: Connecting the transmitter to a power source. This video, from an Avantree Orbit Pro user guide, demonstrates plugging a USB-C cable into the transmitter and then into a TV's USB port for power. (Note: The specific transmitter model shown in the video is Avantree Orbit Pro, but the power connection method is similar).

2.2 TV에 연결하기

The Audikast 3 supports Optical and AUX connections. Choose the option available on your TV.

Avantree Audikast 3 Compatible Devices

Figure 3: Compatible devices and connection types for Audikast 3. This image shows the transmitter's ports (Optical, AUX) and lists compatible TV audio outputs.

Option 1: Optical Audio Output

  • Connect one end of the optical audio cable to your TV's "Optical Out" port.
  • Connect the other end to the "Optical In" port on the Audikast 3.
  • Ensure the input switch on the Audikast 3 is set to "OPT".

Option 2: AUX Audio Output

  • Connect one end of the 3.5mm AUX audio cable to your TV's "AUX Out" or headphone jack.
  • Connect the other end to the "AUX In" port on the Audikast 3.
  • Ensure the input switch on the Audikast 3 is set to "AUX".

TV 오디오 설정: After connecting, access your TV's sound settings menu. Ensure the audio output is set to the corresponding port (Optical or AUX) and the audio format is set to "PCM" if using optical.

2.3 Pairing with Headphones (Audikast 3 & TWS116)

To pair your TWS116 headphones with the Audikast 3 transmitter:

  1. Put your TWS116 headphones into pairing mode (refer to the headphone manual for specific instructions).
  2. On the Audikast 3, press the "검색 Devices" button once.
  3. Use the arrow buttons to select "Avantree TWS116" from the list on the transmitter's screen.
  4. Press the "Connect" button. The connection status will show "Connected" on the screen.
Avantree Audikast 3 Dual Link

Figure 4: Dual Link feature of Audikast 3. This image shows two people wearing headphones connected to the transmitter, illustrating the dual link capability.

듀얼 링크: To connect a second pair of headphones, put the second pair into pairing mode and repeat steps 2-4. The Audikast 3 can transmit to two Bluetooth headphones simultaneously.

2.4 Using with a Soundbar (Bypass Function)

The Audikast 3 supports a bypass function, allowing you to listen through both your soundbar/external speaker and your headphones simultaneously. Ensure your soundbar is connected to the Audikast 3's output port using the same connection type (Optical or AUX) as the input from your TV.

Video 2: Using the transmitter with a soundbar. This video, from an Avantree Orbit Pro user guide, illustrates connecting a soundbar to the transmitter's output while also transmitting to headphones. (Note: The specific transmitter model shown in the video is Avantree Orbit Pro, but the bypass connection method is similar).

2.5 Using as a Wireless Audio Receiver (RX Mode)

The Audikast 3 can also function as a Bluetooth receiver, allowing you to stream audio from your phone/tablet to a wired speaker or stereo system.

  1. Flip the mode switch on the Audikast 3 to "RX".
  2. Connect your wired speaker/stereo system to the Audikast 3's output port (Optical or AUX).
  3. On your phone/tablet, go to Bluetooth settings and search for "Avantree Audikast 3" to pair.

Video 3: Using the transmitter as a wireless audio receiver. This video, from an Avantree Orbit Pro user guide, demonstrates switching the device to RX mode and pairing it with a smartphone to stream audio to an external speaker. (Note: The specific transmitter model shown in the video is Avantree Orbit Pro, but the RX mode functionality is similar).

3. Operating - TWS116 Headphones

3.1 Reconnecting Headphones

Once successfully paired, your TWS116 headphones should automatically reconnect to the Audikast 3 when both devices are turned on. If not, simply press the "Connect" button on the Audikast 3 once to initiate reconnection.

3.2 헤드폰 컨트롤

Avantree TWS116 Built-in Controls

Figure 5: Built-in controls on TWS116 headphones. This image shows the touch-sensitive areas on the headphones for controlling playback, volume, and calls.

The TWS116 headphones feature intuitive touch controls:

  • 재생/일시 중지: 양쪽 이어버드를 한 번 탭하세요.
  • 볼륨 높이기/낮추기: Tap and hold on the right/left earbud respectively.
  • 다음 / 이전 트랙 : Double tap on the right/left earbud respectively.
  • 전화 받기/종료: 양쪽 이어버드를 한 번 탭하세요.
  • Voice Assistant 활성화 : 양쪽 이어버드를 세 번 탭하세요.

4. 유지관리

To ensure the longevity and optimal performance of your Avantree devices:

  • Keep devices clean and dry. Avoid exposure to liquids.
  • 직사광선을 피해 시원하고 건조한 곳에 보관하세요.
  • Do not attempt to disassemble or repair the devices yourself.
  • 제공된 충전 케이블과 어댑터만 사용하세요.

5. 문제 해결

문제가 발생하면 다음의 일반적인 해결 방법을 시도해 보세요.

  • 소리 없음:
    • Ensure both the Audikast 3 and headphones are powered on and paired.
    • Verify TV audio output settings (PCM for optical, correct port for AUX).
    • 모든 케이블 연결을 확인하십시오.
  • 낮은 볼륨:
    • Adjust volume on both the headphones and the Audikast 3.
    • If using optical, ensure the Audikast 3's volume boost feature is active.
  • 립싱크 지연:
    • Ensure both the Audikast 3 and your headphones support aptX-Adaptive or Low Latency codecs.
  • Interference/Poor Connection:
    • Keep devices within range and away from other wireless devices.
    • Ensure there are no physical obstructions between the transmitter and headphones.

6. 사양

Avantree Audikast 3 Transmitter:

  • 연결 기술 : Optical, AUX
  • 무선 통신 표준: 블루투스 5.3
  • 호환 장치: Headphones, Speakers, Televisions, Other audio sources

Avantree TWS116 Headphones:

  • 설계: 오픈이어
  • 특징: Charging Dock, Surroundings Awareness

7. 안전 정보

다음 안전 지침을 준수하십시오.

  • 액체에 노출되지 않도록 하십시오.
  • 취침 중에는 사용하지 마십시오.
  • Be aware of other wireless devices in the vicinity to avoid interference.
  • Do not attempt to open or modify the devices.
  • 어린이의 손이 닿지 않는 곳에 보관하세요.

8. 보증 및 지원

This product comes with a standard return policy allowing for refund/replacement within 30 days. For further support or warranty claims, please visit the official Avantree web사이트를 방문하거나 고객 서비스에 문의하세요.
