제품 끝view
The Fieldpiece SM482V is an advanced wireless 4-port SMAN refrigerant manifold designed for comprehensive HVAC and Refrigeration diagnostics and service. This digital manifold accurately measures low and high pressure, and calculates superheat and subcooling. It features protected thermocouple jacks for temperature measurements and integrates with Job Link Psychrometer probes for enhanced functionality. The device is built for durability with a heavy-duty casing and IP55 dust and water resistance.
그림 1: 전면 view of the Fieldpiece SM482V Wireless 4-Port SMAN Refrigerant Manifold, showing the digital display and valve controls.
주요 특징
- Accurate measurement of low and high pressure, superheat, and subcooling.
- Integrated vacuum gauge for precise vacuum measurements.
- Protected thermocouple jacks for reliable pipe and outdoor temperature readings.
- Four-valve manifold design for versatile system connections.
- Wireless connectivity to Job Link Psychrometer probes and Job Link System App.
- Data logging capability for up to 168 hours of continuous operation across 9 jobs.
- Temperature compensated system tightness test for leak detection.
- Durable construction with IP55 dust and water resistance.
- Pre-loaded with over 70 refrigerants, including A2Ls.
설정 및 초기 사용
- 배터리 설치: Open the battery compartment on the rear of the unit. Insert 6 AA batteries, ensuring correct polarity. Close the compartment securely.
- 전원 켜기: Press the power button to turn on the manifold. The display will illuminate and show initial readings.
- 냉매 선택: Use the "SELECT" button to cycle through the pre-loaded refrigerants. Choose the appropriate refrigerant for your application.
- Zero Pressure: Before connecting to a system, ensure all valves are closed and press the "ZERO PRESSURE" button to calibrate the pressure sensors.
- 프로브 연결하기: Connect thermocouple pipe clamps to the protected jacks for temperature measurements. For wireless integration, ensure Job Link Psychrometer probes are paired according to their respective manuals.
Figure 2: The SM482V manifold being connected to an HVAC system, demonstrating hose attachment points.
작동 지침
Pressure and Temperature Measurement
Connect the manifold hoses to the high and low-pressure ports of the HVAC/R system. Open the appropriate valves on the manifold to read system pressures. The display will show real-time pressure readings, along with superheat and subcooling calculations based on connected temperature probes.
Vacuum Measurement
To measure vacuum, connect the vacuum pump to the manifold's vacuum port. Open the vacuum valve and start the pump. The integrated micron gauge will display the vacuum level. Monitor the reading until the desired vacuum is achieved.
System Tightness Test (Nitrogen Pressure Test)
The SM482V features a temperature-compensated nitrogen pressure test. Connect a nitrogen tank to the system via the manifold. Press the "N2 TEST" button to initiate the test. The manifold will record the initial pressure and monitor for pressure differential (Pdif) over time, indicating potential leaks. Press "STOP/EXIT" to end the test.
데이터 로깅
The manifold can log up to 168 hours of data. To start data logging, refer to the specific instructions in the full user manual or the Job Link System App. Logged data can be retrieved and analyzed via the Job Link App.
Figure 3: An HVAC technician using the Fieldpiece SM482V on an outdoor air conditioning unit.
유지
- 청소: 광고로 장치를 닦으세요amp 천. 연마성 세척제나 용매를 사용하지 마십시오.
- 배터리 교체: Replace batteries when the low battery indicator appears on the display. Always use 6 new AA alkaline batteries.
- Hose and Gasket Inspection: Regularly inspect hoses and manifold gaskets for wear and tear. Replace damaged components to ensure accurate readings and prevent leaks.
- 저장: Store the manifold in its soft case in a dry environment, away from extreme temperatures.
- 펌웨어 업데이트: Periodically check the Fieldpiece website or Job Link App for firmware updates to ensure optimal performance and access to new features.
Figure 4: The Fieldpiece SM482V manifold alongside its protective soft case.
문제 해결
| 문제 | 가능한 원인 | 해결책 |
|---|---|---|
| 부정확한 압력 판독값 | Uncalibrated sensors, leaky hoses/gaskets, incorrect refrigerant selected. | Perform "ZERO PRESSURE" calibration. Inspect and replace worn hoses or gaskets. Verify correct refrigerant is selected. |
| Vacuum Reading Fluctuations | Moisture in system, internal manifold leak, contaminated hoses. | Ensure system is thoroughly evacuated. Check manifold for internal leaks (refer to service manual). Purge hoses with nitrogen before vacuuming. |
| 디스플레이가 켜지지 않음 | 배터리 방전, 배터리 설치 오류. | Replace batteries with new ones. Check battery polarity. |
| 무선 연결 문제 | Out of range, interference, un-paired probes. | Ensure manifold and probes are within range (up to 1000ft line of sight). Reduce interference sources. Re-pair probes according to their instructions. |
명세서
| 특징 | 세부 사항 |
|---|---|
| 모델 | SM482V |
| 품목 무게 | 5.79파운드(2.63kg) |
| 제품 크기(L x W x H) | 5 x 10.25 x 11.25인치(12.7 x 26.0 x 28.6cm) |
| 재료 | ABS 플라스틱 |
| 전원 | 6개의 AA 배터리 |
| 배터리 수명 | 405 hours (with backlight and wireless OFF) |
| 표시하다 | 5" (12.7 cm) LCD w/ backlight |
| 무선 범위 | 1000' (305 m) line of sight |
| Maximum Manifold Pressure | 870파운드(6000kPa) |
| 진공 포트 | 3/8" for fast evacuations |
| Refrigerant Recovery/Charging Port | 1/4인치 |
| Suction Line and Liquid Line Ports | 1/4인치 |
| 침투 방지 등급 | IP55 (Dust/Water Resistance) |
| 운영 환경 | 14° to 122° F (-10° to 50° C) at <75% RH |
| 저장 환경 | -4° to 140° F (-20° to 60° C) at <80% RH (w/o batteries) |
| 데이터 포트 | USB-C for extracting data logs and updating firmware |
Figure 5: Detailed specifications table comparing SM382V and SM482V models.
보증 정보
The Fieldpiece SM482V Wireless 4-Port SMAN Refrigerant Manifold comes with a 1년 한정 보증 from the date of purchase. This warranty covers defects in materials and workmanship under normal use. For detailed warranty terms, conditions, and limitations, please refer to the official warranty document included with your product or visit the Fieldpiece official web대지.
메모: The warranty does not cover damage caused by misuse, accident, unauthorized modification, neglect, or improper operation.
지원 및 연락처 정보
For technical assistance, product inquiries, or warranty claims, please contact Fieldpiece customer support through the following channels:
- 공식적인 Web대지: 방문하세요 Fieldpiece Store on Amazon 제품 정보, FAQ, 지원 리소스를 확인하세요.
- 제조업체: 필드피스 계측기
- 온라인 리소스: Check for updated manuals, firmware, and troubleshooting guides on the official Fieldpiece web대지.
When contacting support, please have your product model number (SM482V) and purchase date available.
