1. 서론
The TP-Link VIGI NVR2016H is a 16-channel network video recorder designed for comprehensive surveillance systems. It supports 4K HDMI video output and offers a 16MP decoding capacity, ensuring high-resolution video capture and playback. This NVR utilizes H.265+ video compression for efficient storage and network usage, is ONVIF compatible for broad camera integration, and features plug-and-play functionality for simplified setup. It also includes two-way audio and remote monitoring capabilities.
그림 1: 전면 view of the TP-Link VIGI NVR2016H Network Video Recorder.
2. 주요 특징
The VIGI NVR2016H offers a range of features to enhance your surveillance experience:
- 4K HDMI Video Output & 16MP Decoding Capacity: Provides sharp image definition up to 8MP (4K) and supports 8-channel at 2MP decoding for simultaneous live view 및 재생.
- 16-Channel Simultaneous Playback: 다시 허용view잉푸tage from up to 16 cameras concurrently, with options to increase replay speed and locate events via the video schedule.
- H.265+ 비디오 압축: Reduces video file size without compromising quality, optimizing network bandwidth and storage space.
- ONVIF 호환성: Ensures seamless integration with VIGI and other ONVIF-compliant IP cameras, facilitating flexible network expansion.
- 플러그 앤 플레이: Automatically detects and activates new VIGI IP Cameras, simplifying the installation process.
- 양방향 오디오 : Supports voice intercom for communication and deterrence.
- 원격 모니터링: 실시간 액세스 views and playback via the VIGI app or client software from anywhere.
Figure 2: Visual representation of the NVR's core functionalities.
3. 제품 오버view
Familiarize yourself with the physical components and ports of the VIGI NVR2016H.
Figure 3: Rear panel connections and their functions.
- 전원 공급 장치: 제공된 전원 어댑터를 여기에 연결하세요.
- USB 2.0 포트: Two ports for connecting a mouse, keyboard, or external hard disk.
- HDMI and VGA Ports: For simultaneous video output to a monitor.
- eSATA 포트: Connect an external storage device for expanded capacity.
- AUDIO IN and AUDIO OUT: For two-way audio functionality.
- LAN 포트: 네트워크에 이더넷으로 연결하려면.
4. 설정 가이드
Follow these steps to set up your VIGI NVR2016H:
4.1 초기 하드웨어 연결
- 하드 디스크 드라이브(HDD) 설치: NVR c를 엽니다.asing and securely install one or two SATA HDDs (up to 10TB each) using the provided screws. Ensure the HDD is properly connected to the SATA data and power cables.
- 모니터 연결: NVR의 HDMI 또는 VGA 포트에 모니터를 연결하세요.
- 마우스 연결: USB 마우스를 NVR의 USB 포트 중 하나에 연결하세요.
- 네트워크에 연결: Use an Ethernet cable to connect the NVR's LAN port to your router or network switch.
- 전원 켜기: 전원 어댑터를 NVR에 연결하고 전원 콘센트에 꽂으세요. NVR이 자동으로 켜집니다.
4.2 Camera Connection and Initialization (Plug & Play)
The VIGI NVR supports Plug & Play for VIGI IP Cameras, simplifying the addition of new cameras.
Figure 4: Plug & Play camera connection process.
- 간단한 연결: Connect your VIGI IP Cameras to the same network as the NVR (e.g., via a TP-Link Switch).
- Auto Initialize: On the NVR interface, enable the "Auto Initialize" function. The NVR will automatically detect and add new VIGI IP Cameras.
- 끝난: Once detected, the cameras will be activated and ready for use, making installation faster and easier.
5. 사용 설명서
5.1 라이브 View
NVR을 사용하면 다음을 수행할 수 있습니다. view live feeds from up to 16 cameras simultaneously on a single screen.
Figure 5: 16-Channel Simultaneous Live View.
Navigate the on-screen display using the connected mouse to select specific camera feeds, adjust display layouts, or access camera settings.
5.2 재생
Review 기록된 footage efficiently with the NVR's playback features.
Figure 6: 16-Channel Simultaneous Playback Timeline.
Access the playback menu to select specific dates and times. The timeline displays recorded events, allowing for quick navigation. You can increase playback speed to review 푸tage faster and easily find specific incidents.
5.3 녹음
The NVR supports continuous recording and efficient storage management.
Figure 7: 24/7 Continuous Recording and Storage Capacity.
- 24시간 연중무휴 연속 녹화: The NVR automatically and continuously stores footage 연결된 카메라에서.
- H.265+ 압축: 이 고급 비디오 압축 기술은 화질을 개선합니다. file sizes significantly, allowing for more footage to be stored on the same disk space while maintaining video quality.
- 저장 용량: Supports up to 20 TB of storage across two HDDs (10TB per HDD).
5.4 양방향 오디오
Utilize the two-way audio feature for interactive communication through connected cameras that support this function.
그림 8: 양방향 오디오 작동 모습.
Connect a microphone to the AUDIO IN port and speakers to the AUDIO OUT port on the NVR to enable this feature. This allows for voice intercom support, useful for deterring intruders or communicating with individuals near the cameras.
5.5 원격 모니터링
Access and manage your surveillance system remotely using the VIGI app or VIGI Security Manager software.
Figure 9: Remote Management via VIGI App and Software.
- 살다 Views and Real-Time Alerts: Monitor your cameras in real-time and receive instant notifications for detected events.
- Easy & Smart Playback: Review 기록된 footage conveniently from your mobile device or computer.
- Customized Monitoring Patterns: Configure specific monitoring schedules and alert settings.
- Four-Way Management: Manage your cameras flexibly via the web UI, NVR UI, VIGI app, and VIGI Security Manager.
6. 유지관리
6.1 하드 디스크 드라이브(HDD) 관리
Regularly check the status of your installed HDDs through the NVR's interface to ensure optimal recording performance. If an HDD fails or reaches its capacity, you may need to replace it or configure overwriting settings.
6.2 펌웨어 업데이트
TP-Link regularly provides software updates to improve performance, add features, and enhance security. It is recommended to check for and install available firmware updates through the NVR's system settings or the TP-Link support website to ensure your device operates with the latest functionalities and security patches.
7. 문제 해결
7.1 NVR Stuck on TP-Link Screen During Boot
If the NVR gets stuck on the TP-Link logo screen during its initial boot or after an update, this can sometimes be a minor software glitch. To resolve this:
- 전원 끄기 : Disconnect the power adapter from the NVR.
- Access Reset Button: Carefully open the NVR casing to locate the internal reset button.
- 재설정 버튼을 누르세요: Press and hold the reset button for a few seconds.
- 장치 재시작: Reconnect the power adapter. The NVR should now boot normally.
7.2 동작 감지 문제
If motion detection behaves erratically (e.g., continuous detection without apparent reason), review your camera's motion detection settings. Adjust sensitivity levels, detection zones, and schedules to optimize performance and reduce false alarms. Ensure camera firmware is up to date.
7.3 No LAN Cable Included
While some NVR packages may not include a LAN cable, a wired internet connection is essential for the system's proper functioning. Ensure you have a standard Ethernet cable to connect the NVR to your network.
8. 사양
| 특징 | 세부 사항 |
|---|---|
| 모델 번호 | 비지 NVR2016H |
| 제조업체 | TP-LINK 주식회사 |
| 제품 치수 | 14.2 x 36.8 x 40cm |
| 품목 무게 | 1.89kg |
| 채널 수 | 16 |
| 메모리 저장 용량 | 20 TB (2 x 10TB HDDs) |
| 연결 기술 | 열광한 |
| 호환 장치 | 카메라 |
9. 상자 안에 무엇이 들어있나요?
제품 패키지에는 다음 항목이 포함되어 있습니다.
- VIGI 네트워크 비디오 레코더
- 전원 어댑터
- HDD 나사
- 생쥐
- 빠른 설치 가이드
10. 지원 및 보증
For technical support, warranty information, or further assistance, please contact TP-Link customer service.
- 수입자/제조업체: TP-Link India Private Limited
- 주소: Office No.1, Tower 2, Level 2, Raiaskaran Tech Park, Andheri Kurla Road, M.V Road, Andheri East-400072
- 무료 전화: 1800-209-4168
- 이메일: support.in@tp-link.com
Please refer to the official TP-Link website or the Quick Installation Guide for the most up-to-date support resources and warranty details applicable to your region.
