1. 서론
This manual provides essential information for the safe and effective operation of your MASINGO Allegro X8 2.0 Professional Karaoke Machine. Please read all instructions carefully before use and retain this manual for future reference.
Figure 1: MASINGO Allegro X8 2.0 Professional Karaoke Machine
2. 상자 안에 무엇이 들어있나요?
패키지에 모든 품목이 들어 있는지 확인하세요.
- 알레그로 X8 노래방 기계
- 2 무선 마이크
- 충전 어댑터
- 사용자 설명서
- 보조 케이블
Figure 2: All-inclusive karaoke equipment
3. 설정
3.1 초기 충전
Before first use, fully charge the karaoke machine using the provided charging adapter. The unit features a rechargeable battery providing 3-4 hours of operation.
3.2 마이크 설정
Insert AA batteries into each wireless microphone. The microphones are rechargeable via USB-C (cable not included for microphones, but the main unit's charging adapter is provided).
Figure 3: Dual crystal-clear wireless microphones
3.3 Wi-Fi 연결
Power on the unit. On the touchscreen, navigate to 'Settings' and connect to your local Wi-Fi network for online content access.
4. 사용 설명서
4.1 Touchscreen Tablet
The Allegro X8 2.0 features a built-in 14.1-inch touch screen tablet. It comes with pre-installed apps like YouTube, Spotify, Apple Music, and Chrome. You can also download additional apps from the Play Store.
Figure 4: Lyrics display from built-in music apps
4.2 무선 마이크
The two wireless microphones feature individual displays for battery levels and frequency. Adjust microphone volume, echo, and EQ directly on the microphones or via the main control panel for optimal sound.
4.3 연결 옵션
The unit supports multiple playback modes:
- 태블릿 모드: Utilize the built-in touchscreen for apps and content.
- 블루투스: Connect wirelessly to your smartphone or other Bluetooth-enabled devices.
- USB: USB 드라이브에서 미디어를 직접 재생하세요.
- AUX-out: 외부 오디오 시스템에 연결하세요.
- 마이크로 SD: Play media from a Micro-SD card.
- HDMI : Output video to an external display or TV.
- 기타 입력: Connect a guitar to use the unit as an amp리퍼.
Figure 5: Top control panel with various inputs and adjustments
4.4 Voice Effects (Magic Mode)
Engage 'Magic Mode' to alter your voice with various effects such as 'Man', 'Woman', 'Electric', and 'Shout'. These settings can be adjusted for enhanced karaoke experiences.
4.5개의 LED 조명
The speaker features colorful LED lights that change in sync with the music, adding a dynamic visual element to your performance. These can be controlled via the unit's buttons.
4.6 이식성
The Allegro X8 2.0 is designed for portability with wheels and a telescoping handle, allowing for easy transport. The internal rechargeable battery provides 3-4 hours of continuous use.
Figure 6: Rolling speaker with telescoping handle for easy transport
4.7 공식 제품 영상
Video 1: Introduction to the MASINGO Allegro X8 2.0 Karaoke Machine, showcasin기능과 휴대성을 고려했습니다.
5. 유지관리
To ensure longevity and optimal performance of your karaoke machine:
- 부드럽고 마른 천으로 닦아서 제품을 깨끗하게 유지하십시오.
- 본 제품을 극한의 온도나 습기에 노출시키지 마십시오.
- 사용하지 않을 때는 시원하고 건조한 곳에 보관하세요.
- Ensure microphones are fully charged before each use.
6. 문제 해결
If you encounter issues with your Allegro X8 2.0, try the following:
- 전원 없음: Ensure the unit is fully charged or connected to the charging adapter. Check the power switch.
- 마이크가 연결되지 않습니다: Ensure microphones have fresh batteries and are powered on. Re-pair them if necessary.
- 소리 없음: Check volume levels on both the main unit and microphones. Ensure correct input source is selected.
- 터치스크린이 반응하지 않음: Restart the unit. If the issue persists, contact customer support.
- 느린 성능: Ensure a stable Wi-Fi connection. Close unnecessary background applications on the tablet.
7. 사양
- 제품 크기: 18 x 12 x 32 인치
- 품목 무게: 36.4파운드
- 품목 모델 번호: Allegro X8 - 2.0 Model
- 상표: MASINGO
- 특징: Cordless, Portable, Wireless
- 색상: 그레이 (2.0)
- 제품의 권장 용도: 집
그림 7: 제품 치수
8. 보증 및 지원
그들을ASINGO Allegro X8 2.0 Karaoke Machine comes with a 60-day warranty. For further assistance or warranty claims, please refer to the contact information provided in your product packaging or visit the MASINGO 공식 web대지.
