VASTFIRE LEP + LED Combo Flashlight User Manual

소개

Thank you for choosing the VASTFIRE LEP + LED Combo Flashlight. This powerful and versatile flashlight is designed for various applications, offering exceptional brightness and long-distance illumination. Its durable construction and intelligent features make it an ideal tool for outdoor activities, emergency situations, and everyday carry.

Figure 1: The VASTFIRE LEP + LED Combo Flashlight in use, demonstrating its powerful beam illuminating a wide area at night.

설정

1. 초기 배터리 준비

Before first use, ensure the battery is properly installed and any protective packaging is removed. The flashlight comes with a pre-installed Lithium Polymer battery. To activate the flashlight, it is crucial to remove the cardboard disc located in the battery compartment. This disc prevents battery contact during shipping.

1. 손전등의 테일 캡을 푸십시오.
2. Locate and remove the small cardboard disc placed between the battery and the contact point.
3. 배터리가 올바른 극성(+/-)으로 삽입되었는지 확인하세요.
4. 꼬리 캡을 다시 단단히 조여 고정합니다.

2. 배터리 충전

이 손전등은 내장형 Type-C 충전 포트를 갖추고 있으며 보조 배터리 기능도 제공합니다.

• Connect the provided USB-C charging cable to the flashlight's Type-C port.
• Connect the other end of the cable to a compatible USB power source (e.g., wall adapter, computer, car charger).
• The intelligent power indicator on the side switch will show the charging status:
  • 빨간불: Battery is charging (Power < 20%).
  • 녹색불: Battery is fully charged (Power > 20%).
• 일반적으로 완전 충전에는 약 8시간이 걸립니다.

Figure 2: Illustration of the flashlight's power bank functionality and charging indicators, showing the Type-C port and battery status lights.

작동 지침

1. 전원 켜기/끄기 및 밝기 모드

The flashlight features multiple brightness levels and special modes for various situations.

• 전원 켜기: Single-click the side switch to turn the flashlight on.
• 밝기 조절: While the flashlight is on, single-click the side switch to cycle through the three brightness levels: High (5000 lumens) → Medium (3000 lumens) → Low (1000 lumens).
• Maximum Brightness (Turbo): Double-click the side switch from any state (on or off) to instantly activate the maximum brightness (5000 lumens).
• 스트로브 모드: Long-press the side switch for approximately 2 seconds to activate Strobe mode (3000 lumens).
• 구조 요청 모드: While in Strobe mode, single-click the side switch to switch to SOS mode (3000 lumens).
• 전원 끄기 : Long-press the side switch for approximately 2 seconds from any mode to turn the flashlight off. Alternatively, if the flashlight has been on for more than 5 seconds in any mode, a single click will turn it off directly without cycling through modes.

Figure 3: Detailed table outlining the different brightness levels, runtimes, and throw distances for the flashlight's various modes.

2. Adjustable Focus (LEP + LED Combo)

이 손전등은 초점 조절 메커니즘을 갖추고 있어 넓은 범위의 확산광과 집중광 사이를 전환할 수 있습니다.

• 초점을 조절하려면 손전등 헤드를 앞뒤로 부드럽게 움직이세요.
• Sliding the head forward will narrow the beam, creating a powerful spotlight for long-distance illumination (up to 1,260 yards).
• Sliding the head backward will widen the beam, providing a broad floodlight for illuminating a large area.

Figure 4: The flashlight's adjustable focus feature, showing the transition from a wide floodlight to a narrow, long-throw spotlight.

3. 파워뱅크 기능

The VASTFIRE flashlight can also serve as a portable power bank to charge your mobile devices.

• Locate the USB-A output port next to the Type-C input port.
• 기기의 충전 케이블을 손전등의 USB-A 출력 포트에 연결하세요.
• The flashlight's 5000 mAh capacity can provide a quick charge to your phone or other small electronics in a pinch.

유지

1. 청소

최적의 성능을 유지하려면 손전등을 깨끗하게 관리하십시오. 본체를 부드러운 천으로 닦으십시오.amp 렌즈에는 흠집 방지를 위해 렌즈 클리닝 천을 사용하십시오.

2. 방수(IPX6)

The VASTFIRE flashlight is rated IPX6 water-resistant, meaning it can withstand powerful water jets. It is suitable for use in rain or snowy conditions, but it is 침수용으로 설계되지 않음 물속에서.

Figure 5: The flashlight's IPX6 water resistance is shown, highlighting its reliability in wet environments like rain or snow.

3. Impact Resistance

Constructed from durable aircraft-grade aluminum alloy, the flashlight is designed to withstand impacts. It has a 1-meter impact resistance rating, ensuring durability in rugged conditions.

Figure 6: Visual representation of the flashlight's robust construction and its ability to withstand impacts from a height of 1 meter.

문제 해결

• 손전등이 켜지지 않음: Ensure the cardboard disc has been removed from the battery compartment during initial setup. Check that the battery is inserted with the correct polarity.
• 배터리가 충전되지 않음: If the flashlight's battery life significantly decreases over time, it may indicate a need for battery replacement. Ensure you are using the provided charging cable and a reliable power source.
• Beam appears distorted or uneven: Adjust the focus mechanism by sliding the head of the flashlight to achieve a clear and even beam.

명세서

보증 및 지원

VASTFIRE offers a 2년 보증 on this product. For any questions, technical support, or warranty claims, please contact VASTFIRE customer service through the retailer's platform or the official VASTFIRE store.

For more information and product updates, visit the official VASTFIRE Store: VASTFIRE Store on Amazon.
