소개
Thank you for choosing the Bosch Series 2 BEL623MS3 Built-in Microwave. This appliance combines microwave functionality with a grill, offering versatile cooking options. This manual provides essential information for the safe and efficient use of your microwave, including installation, operation, maintenance, and troubleshooting.
앞쪽 view of the Bosch Series 2 BEL623MS3 Built-in Microwave, showcasin세련된 디자인과 제어판이 특징입니다.
안전 정보
제품 사용 전 안전 지침을 꼼꼼히 읽어 부상이나 제품 손상을 방지하십시오. 나중에 참조할 수 있도록 이 설명서를 보관하십시오.
- 전자레인지가 제대로 접지되었는지 확인하십시오.
- 전자레인지 문이 손상되었거나 고무 패킹이 마모된 경우에는 작동하지 마십시오.
- Only use microwave-safe cookware. Metal containers are not suitable for microwave mode.
- Never heat sealed containers or baby bottles with narrow necks, as they may explode.
- 기기를 사용하는 동안 어린이를 감독하십시오.
- 기기를 직접 수리하거나 정비하려고 하지 마십시오. 자격을 갖춘 서비스 담당자에게 문의하십시오.
설정 및 설치
The Bosch BEL623MS3 is designed for built-in installation. Proper installation is crucial for safety and performance. Refer to the dimension diagram and the installation video for detailed guidance.
설치 치수
Detailed diagram showing the required dimensions in millimeters for built-in installation of the microwave. Key dimensions include 595mm width, 382mm height, and 335mm depth for the appliance, with specific cabinet opening requirements.
구성 요소 배치
Before first use, ensure all internal components are correctly placed:
- Place the glass turntable securely on its support.
- For grill functions, position the metal grill rack on the turntable.
내부 view of the microwave showing the glass turntable and the metal grill rack placed inside.
Installation and Use Video
Watch this video for a visual guide on installing and setting up your Bosch microwave, including placing internal accessories.
This video demonstrates the installation process of the Bosch BEL623MS3 microwave and how to correctly place its internal components like the turntable and grill rack.
작동 지침
Your Bosch microwave offers various functions for heating, cooking, and grilling. The LED display and control knob facilitate easy operation.
The microwave with its door open, revealing the interior and the control panel on the right.
Basic Microwave Function
- 음식을 전자레인지용 용기에 담아 회전판 위에 올려놓습니다.
- 전자레인지 문을 닫으세요.
- 조절 손잡이를 사용하여 원하는 조리 시간을 설정하세요.
- Select the power level (e.g., 800W, 600W) using the dedicated buttons.
- Press the 'Start +30 sec' button to begin cooking.
그릴 기능
For optimal grilling results, use the provided grill rack. The grill function is ideal for browning and crisping food.
- 음식을 그릴 랙 위에 올려놓습니다.
- 전자레인지 문을 닫으세요.
- Select the grill function (refer to the specific symbol on the control panel).
- 원하는 그릴 시간을 설정하세요.
- '시작'을 누르세요.
Gourmet Recipes
The microwave features up to 8 pre-programmed gourmet recipes. Simply select the food type and weight, and the microwave will automatically adjust cooking settings for optimal results.
- Press the 'star' button to access pre-programmed recipes.
- Use the control knob to select the desired recipe.
- Enter the weight of the food if prompted.
- '시작'을 누르세요.
제상 기능
The defrost function allows for quick and even thawing of food.
- 냉동식품을 전자레인지용 용기에 담으세요.
- Press the 'kg' button to activate the weight-based defrost function.
- Use the control knob to set the weight of the food.
- '시작'을 누르세요.
Operating the Control Panel Video
This video demonstrates how to use the control panel for various functions, including setting time and power levels.
A demonstration of the microwave's control panel, showing how to set time, power, and use other functions.
유지관리 및 청소
Regular cleaning ensures the longevity and hygiene of your microwave.
- 내부 청소 : 광고로 내부 닦기amp cloth and mild detergent after each use. For stubborn stains, place a bowl of water with lemon juice inside and microwave for a few minutes to loosen residue.
- 외부 청소: 부드러운 천으로 외부 표면을 청소하세요.amp 천으로 닦으세요. 연마성 세제나 강한 화학 물질은 피하세요.
- Turntable and Rack: The glass turntable and metal grill rack can be removed and washed with warm soapy water or in a dishwasher.
- 도어 씰: Regularly check and clean the door seals to ensure they are free from food debris and remain intact.
문제 해결
전자레인지 사용 중 문제가 발생하면 다음의 일반적인 해결 방법을 참고하세요.
| 문제 | 가능한 원인 | 해결책 |
|---|---|---|
| 전자레인지가 시작되지 않음 | Door not closed properly; Power outage; Fuse blown. | Ensure door is fully closed; Check power supply; Reset circuit breaker. |
| 음식이 고르게 가열되지 않음 | 전력량이나 조리 시간이 잘못되었거나, 음식을 섞거나 뒤집지 않았습니다. | Adjust settings; Stir or rotate food halfway through cooking. |
| 작동 중 이상한 소음이 발생합니다. | Turntable not correctly seated; Foreign object inside. | Re-seat turntable; Check for and remove any obstructions. |
| 디스플레이에 오류 코드가 표시됩니다. | 내부 오류. | Refer to the full user manual or contact Bosch customer service. |
If the problem persists after attempting these solutions, please contact Bosch customer support for assistance.
명세서
Here are the key technical specifications for the Bosch Series 2 BEL623MS3 Built-in Microwave:
- 상표: 보쉬
- 모델 번호: BEL623MS3
- 설치 유형: 내장형
- 색상: Black and Steel
- 용량: 20리터
- 왓tage: 800 와트
- 권tage: 230 볼트
- 제품 크기(깊이 x 너비 x 높이): 33.5 x 59.5 x 38.2cm
- 무게: 14.3kg
- 재료: 스테인리스 스틸
- 특별 기능: Defrost, Grill, LED Display, Gourmet Recipes
- 포함된 구성 요소: 1 x Microwave, 1 x Turntable, 1 x Grill Rack
보증 및 지원
Your Bosch BEL623MS3 microwave comes with a manufacturer's warranty. Please refer to the warranty card included with your purchase for specific terms and conditions. For technical support, spare parts, or service inquiries, please visit the official Bosch web사이트 또는 고객 서비스 부서에 문의하십시오.
보쉬 고객 서비스: www.bosch-home.com
