Leviton 21254-HW 20A 125V Hospital Grade 4-in-1 Receptacle Instruction Manual

1. 제품 오버view

The Leviton 21254-HW is a 20 Amp, 125 Volt, Industrial Series Extra Heavy Duty Hospital Grade 4-in-1 Receptacle. Designed for demanding environments, this straight blade, grounding receptacle provides four outlets in a single unit, suitable for applications requiring high-abuse tolerance such as healthcare facilities, manufacturing plants, and schools. It features a durable nylon body and face, a 5-20R configuration, and is approved by UL 498, CSA C22.2, and ISO 9001 standards.

그림 1: 전면 view of the Leviton 21254-HW 4-in-1 Receptacle, showing the four outlets and 'HOSPITAL GRADE' marking.

2. 안전 정보

경고: To avoid fire, shock, or death, turn OFF power at the circuit breaker or fuse box and test that power is OFF before wiring. This device must be installed in accordance with all national and local electrical codes. If you are unsure about any part of these instructions, consult a qualified electrician.

• Always disconnect power before working on electrical circuits.
• Use only copper wire for connections.
• 감전을 방지하려면 올바르게 접지하십시오.
• 지정된 볼륨을 초과하지 마십시오tag해당 장치의 정격 전류 및 전류 정격.
• Keep children away from electrical work.

3. 제품 특징

• 내구성 있는 구조: Interlocking thermoplastic nylon cover and body for enhanced resilience.
• High Performance Contacts: Extra heavy-duty, T-type triple-wipe bronze contacts ensure maximum electrical performance and longevity.
• 다재다능한 디자인: Accommodates up to four Fed Spec size straight or angled plugs simultaneously.
• 명확한 식별: Easy-to-read voltage와 amperage ratings are molded directly onto the face of the receptacle.
• 인증: UL 498, CSA C22.2, and ISO 9001 approved, ensuring compliance with safety and quality standards.

4. 설정 및 설치

Installation of the Leviton 21254-HW receptacle requires basic electrical knowledge. If you are not comfortable performing electrical work, please consult a licensed electrician.

필요한 도구:

• 드라이버 (십자형 및/또는 일자형)
• 전선 스트리퍼
• 권tag전자 테스터
• 전기 테이프(선택 사항)

설치 단계:

1. 전원 끄기: Locate the circuit breaker or fuse that controls the outlet you are replacing or installing. Turn it OFF. Use a voltage tester to confirm that the power is completely off at the outlet.
2. (해당되는 경우) 기존 용기를 제거하십시오. Unscrew the wall plate and then the mounting screws holding the old receptacle in the electrical box. Carefully pull the old receptacle out of the box.
3. 전선 식별: You will typically find three types of wires:
   • Black or Red (Hot/Line): Carries power.
   • 흰색(중립): Completes the circuit.
   • Green or Bare Copper (Ground): 안전 와이어.
4. 전선 준비: If necessary, strip approximately 1/2 inch of insulation from the end of each wire.
5. Connect Wires to New Receptacle:
   • 연결하다 녹색 또는 베어 구리(접지) ~에 전선을 연결하다 녹색 접지 나사 on the receptacle.
   • 연결하다 흰색(중성) ~에 전선을 연결하다 은나사 터미널.
   • 연결하다 Black or Red (Hot/Line) ~에 전선을 연결하다 황동 나사 터미널.

   Ensure all connections are tight and secure. The receptacle is designed for 3-wire connections.
6. 마운트 수용기: Carefully push the wired receptacle back into the electrical box. Secure it with the mounting screws.
7. 벽면 플레이트 설치: 콘센트 위에 장식용 벽면 플레이트를 부착하세요.
8. 복원력 : Turn the circuit breaker or fuse back ON.
9. 시험: Plug a device into each of the four outlets to ensure proper function.

그림 2: 뒤로 view of the Leviton 21254-HW Receptacle, illustrating the screw terminals for wiring connections (Ground, Neutral, Hot).

5. 사용 설명서

The Leviton 21254-HW 4-in-1 Receptacle operates like any standard electrical outlet. Once properly installed and powered, it is ready for use.

1. Plug In Devices: Insert the plug of your electrical device into any of the four available outlets. The design allows for multiple plugs, including those with larger adapters, to be used simultaneously.
2. 전원 켜기 장치: Turn on your electrical device as usual.

중요한: Do not overload the receptacle or the circuit it is connected to. Ensure the total current draw of all connected devices does not exceed the 20 Amp rating of the receptacle or the circuit breaker.

6. 유지관리

The Leviton 21254-HW receptacle is designed for durability and requires minimal maintenance.

• 청소: To clean the receptacle, ensure power is OFF at the circuit breaker. Wipe the surface with a soft, damp 천. 연마성 세척제나 용매를 사용하지 마십시오.
• 정기 검사: Periodically inspect the receptacle for any signs of damage, such as cracks, discoloration, or loose connections. If any damage is observed, turn off power and replace the receptacle immediately.
• 연결부의 밀착도: If you suspect a loose connection, turn off power at the circuit breaker and carefully check the wire terminals for tightness.

7. 문제 해결

If you encounter issues with your Leviton 21254-HW receptacle, consider the following troubleshooting steps:

No Power at Receptacle:

• 회로 차단기를 확인하십시오. Verify that the circuit breaker controlling the receptacle is in the ON position. If it has tripped (moved to the OFF or middle position), reset it by pushing it firmly to OFF and then to ON.
• 다른 콘센트 테스트: Check if other outlets on the same circuit are working. If not, the issue is likely with the circuit breaker or wiring to the circuit.
• 배선 검사: With power OFF at the breaker, carefully remove the wall plate and receptacle. Check that all wires are securely connected to their respective terminals (Hot to Brass, Neutral to Silver, Ground to Green). Ensure no wires are loose or frayed.
• 초과 적재: Ensure the total load of devices plugged into the receptacle does not exceed 20 Amps. Unplug some devices and retest.

플러그 연결이 헐거워졌습니다.

• The Leviton 21254-HW features heavy-duty contacts designed for secure connections. If a plug feels loose, ensure it is fully inserted. If the issue persists with multiple plugs, the receptacle may be worn and require replacement.

문제 해결 단계를 시도해도 문제가 해결되지 않으면 자격을 갖춘 전기 기술자에게 문의하십시오.

8. 사양

Figure 3: Product dimensions of the Leviton 21254-HW Receptacle.

9. 보증 및 지원

For warranty information and technical support regarding your Leviton 21254-HW receptacle, please refer to the official Leviton website or contact Leviton customer service directly. Warranty terms typically cover defects in materials and workmanship under normal use.

Leviton Customer Service: 도움이 필요하시면 다음을 방문하세요. Leviton Store on Amazon 또는 공식 회사 web대지.
