1. 서론
This instruction manual provides essential information for the proper installation and maintenance of your Leviton 84026 2-Gang Standard Size Magnetic Stainless Steel Wallplate. Please read these instructions thoroughly before beginning installation to ensure safe and correct usage.
The Leviton 84026 wallplate is designed for 2-gang flush mount applications, featuring a 2.15-inch diameter device receptacle opening. It is constructed from magnetic stainless steel, offering durability and a smooth finish.
2. 안전 정보
WARNING: Risk of Electric Shock. Turn off power at the circuit breaker or fuse box before installation.
- Always ensure power is disconnected before handling electrical components.
- 설치 과정 중 확실하지 않은 부분이 있으면 자격을 갖춘 전기 기술자에게 문의하십시오.
- 본 제품은 실내에서만 사용하도록 설계되었습니다.
- 젖어 있거나 d인 곳에는 설치하지 마십시오.amp 위치.
- 모든 연결이 안전한지 확인하고 현지 전기 규정을 준수하세요.
3. 패키지 내용
설치를 시작하기 전에 모든 구성 요소가 있는지 확인하세요.
- 1 x Leviton 84026 2-Gang Standard Size Magnetic Stainless Steel Wallplate
- Color-matched metal mounting screws
4. 설치 지침
- 전원 끄기: Locate the circuit breaker or fuse that controls the power to the outlet or switch where the wallplate will be installed. Turn off the power completely. Verify power is off using a voltag전자 테스터.
- Remove Old Wallplate (if applicable): Carefully unscrew and remove the existing wallplate.
- Prepare New Wallplate: The Leviton 84026 wallplate ships with a protective film (blue or clear) to prevent scratches during shipping and handling. This film must be removed prior to installation for optimal appearance.
Image: A Leviton 2-Gang Stainless Steel Wallplate with a corner of the blue protective film being peeled off, revealing the brushed stainless steel underneath. This demonstrates the protective film removal process.
이미지: 클로즈업 view of a finger carefully peeling the blue protective film from the edge of a stainless steel wallplate, highlighting the smooth finish beneath.
- Position Wallplate: Align the new Leviton 84026 wallplate over the electrical device(s) and the wall box. Ensure the openings on the wallplate match the device configuration.
- Secure Wallplate: Use the provided color-matched metal mounting screws to attach the wallplate to the electrical device(s) and/or wall box. Do not overtighten the screws, as this can damage the wallplate or the device.
- 복원력 : 벽면 고정판을 단단히 설치한 후에는 회로 차단기 또는 퓨즈 박스에서 전원을 다시 켜십시오.
5. 유지관리
To maintain the appearance and functionality of your Leviton stainless steel wallplate:
- 청소: Wipe the wallplate with a soft, damp cloth. For stubborn marks, a mild, non-abrasive cleaner suitable for stainless steel can be used. Avoid harsh chemicals, abrasive pads, or scouring powders, as these can scratch the finish.
- 점검: Periodically check the wallplate for any signs of damage or loose screws. Tighten screws as needed, but do not overtighten.
6. 문제 해결
- Wallplate does not fit over device:
- Ensure you have the correct wallplate configuration (e.g., 2-gang, 2.15-inch diameter receptacle opening) for your electrical device. Verify the device is properly seated in the wall box.
- Scratches or dull appearance:
- Confirm that the protective film has been completely removed from the wallplate. If the film was removed, scratches may indicate improper handling or cleaning with abrasive materials. Stainless steel can be polished with appropriate stainless steel cleaners if needed.
- 나사가 조여지지 않습니다.
- Ensure you are using the provided screws and that the screw holes on the electrical device are not stripped. If stripped, the device itself may need replacement.
7. 사양
| 특징 | 세부 사항 |
|---|---|
| 모델 번호 | 84026 |
| 재료 | 자석 스테인리스 스틸 |
| 구성 | 2-Gang, 2.15-inch Diameter Device Receptacle |
| 크기 | 기준 |
| 제품 치수(폭 x 높이) | 0.07" x 0.14" (Note: These dimensions appear to be for thickness/depth, not width/height of the plate itself. Refer to product packaging for full plate dimensions.) |
| 품목 무게 | 2.81 온스 |
| 설치 유형 | 나사로 고정 |
| 마무리 유형 | 매끄러운 |
| 인증 | UL 인증, CSA 인증 획득 |
8. 보증 및 지원
보증 정보
This Leviton product is covered by a manufacturer's warranty. For specific details regarding the warranty period and terms, please refer to the documentation included with your purchase or visit the official Leviton web대지.
고객 지원
For technical assistance, installation questions, or to report any issues with your Leviton product, please contact Leviton Customer Support:
- Web대지: www.leviton.com
- 레비톤을 참조하십시오. website for contact phone numbers and email support options specific to your region.
