소개
Thank you for choosing the ADDIESDIVE AD2075 Automatic Watch. This manual provides essential information for the proper setup, operation, and maintenance of your timepiece. Please read it carefully to ensure optimal performance and longevity of your watch.
제품 끝view
The ADDIESDIVE AD2075 is a 39mm automatic wristwatch featuring an NH35 mechanical movement, a unique bark texture dial, and a durable sapphire crystal. It is designed for daily wear with 100M water resistance.
Figure 1: Close-up of the ADDIESDIVE AD2075 watch dial.
설정
초기 와인딩
Your ADDIESDIVE AD2075 watch is powered by an automatic mechanical movement (NH35) and does not require a battery. Before first use, or if the watch has stopped, it needs to be manually wound. To do this:
- 크라운이 완전히 안쪽으로 밀려 들어간 위치(위치 0)에 있는지 확인하십시오.
- Unscrew the crown counter-clockwise until it springs out slightly (Position 1). This is the winding position.
- Turn the crown clockwise approximately 20 times. This will initiate the movement and build up a power reserve.
- Push the crown back in and screw it clockwise to secure it, ensuring water resistance.
The watch will continue to wind itself through the motion of your wrist while worn. If worn daily for 8-10 hours, manual winding should not be necessary.
시간 및 날짜 설정
시간과 날짜를 설정하려면 :
- Unscrew the crown counter-clockwise until it springs out slightly (Position 1).
- Gently pull the crown out to the first click (Position 2). This position is for setting the date. Turn the crown clockwise or counter-clockwise to adjust the date. Avoid setting the date between 9 PM and 3 AM, as this can damage the movement.
- Gently pull the crown out to the second click (Position 3). This position is for setting the time. Turn the crown to move the hands clockwise until the correct time is displayed. Ensure you differentiate between AM and PM when setting the date.
- Once the time and date are set, push the crown back in to Position 1.
- Screw the crown clockwise firmly against the case to ensure water resistance.
Figure 2: Watch crown in closed position.
작동 지침
자동 이동
The NH35 automatic movement in your watch is self-winding. It harnesses the kinetic energy from your arm's motion to wind the mainspring. When fully wound, the watch has a power reserve that allows it to run for approximately 41 hours without being worn. If the watch is not worn for an extended period, it will stop and require manual winding as described in the "Initial Winding" section.
방수 기능 (100M)
Your ADDIESDIVE AD2075 watch is rated for 100 meters (10 ATM) of water resistance. This means it is suitable for everyday use, including hand washing, light rain, and accidental splashes. It is not suitable for swimming, diving, or showering with hot water. 방수 기능을 유지하려면 크라운이 완전히 조여졌는지 항상 확인하십시오.
Figure 3: ADDIESDIVE AD2075 watch on a wrist.
발광 디스플레이
The watch features Retro Super BGW9 luminous material on its hands and hour markers. This material absorbs light and glows in low-light conditions, providing clear readability in the dark with a soft blue luminescence.
Figure 4: Luminous display of the watch in low light.
유지
청소
시계를 청소하려면 부드럽고 마른 천으로 케이스와 브레이슬릿을 닦으세요. 잘 지워지지 않는 얼룩은 약간 거친 천으로 닦아내세요.amp cloth can be used, ensuring the crown is fully screwed down. Avoid using harsh chemicals, solvents, or abrasive materials, as these can damage the watch's finish and seals.
저장
When not wearing your watch for extended periods, store it in a cool, dry place away from direct sunlight, extreme temperatures, and strong magnetic fields. The original gift box is ideal for storage.
서비스
Mechanical watches benefit from periodic servicing to maintain accuracy and ensure the longevity of the movement. It is recommended to have your watch serviced by a qualified watchmaker every 3-5 years. This includes cleaning, lubrication, and adjustment of the movement.
문제 해결
- 시계가 작동하지 않음: Ensure the watch has been manually wound (approx. 20 turns of the crown) or worn for sufficient time to build power reserve.
- 시간 부정확성: Automatic movements can have slight variations. If the watch is consistently gaining or losing significant time (more than +/- 15-20 seconds per day), it may require adjustment by a professional watchmaker.
- 날짜는 변경되지 않습니다. Check if the date is being set between 9 PM and 3 AM. If so, adjust the time outside this window and then set the date. Ensure the crown is pulled to the correct position for date adjustment.
- 물 유입: If you notice moisture inside the watch, immediately take it to a professional watchmaker. Do not attempt to open the watch yourself. Ensure the crown is always fully screwed down when near water.
명세서
| 특징 | 세부 사항 |
|---|---|
| 모델 번호 | AD2075 |
| 움직임 | NH35 Automatic Mechanical Movement |
| 케이스 소재 | 316L 스테인리스 스틸 |
| 케이스 직경 | 38mm (without crown) |
| 케이스 길이 (러그 간 거리) | 47.5mm |
| 케이스 두께 | 10.5mm (including glass) |
| 러그 폭 | 20mm |
| 결정 | Sapphire Crystal with Blue Light AR Coating |
| 다이얼 색상 | Green (Bark Texture) |
| 발광 | Retro Super BGW9 (Blue Light) |
| 방수성 | 100M(10ATM) |
| 왕관 | 나사로 고정 |
| 밴드 소재 | 스테인리스 스틸 |
| 걸쇠 유형 | 배치 걸쇠 |
| 품목 무게 | 300g |
Figure 5: ADDIESDIVE AD2075 watch dimensions.
보증 및 지원
Your ADDIESDIVE AD2075 watch comes with a warranty card included in the gift box. Please refer to this card for specific warranty terms and conditions. For any support inquiries, technical assistance, or warranty claims, please contact the retailer or manufacturer directly using the contact information provided with your purchase or on the official ADDIESDIVE web대지.
포함된 구성 요소: Stainless Steel Bracelet, Gift Box, Warranty Card.
