1. 서론
The KKB G200 4G LTE Cellular Security Camera is designed for robust outdoor surveillance in locations without traditional Wi-Fi access. This solar-powered, wire-free camera offers 2K HD resolution, color night vision, two-way audio, and remote monitoring via a dedicated mobile application. Its integrated 4G LTE connectivity ensures continuous operation and real-time alerts, making it ideal for farms, construction sites, remote cabins, and other off-grid environments.
Figure 1: KKB G200 4G LTE Cellular Security Camera and Solar Panel.
2. 패키지 내용
패키지에 모든 품목이 들어 있는지 확인하세요.
- 1 x KKB 4G LTE Security Camera
- 1 x 5W 태양광 패널
- 1 x Built-in SIM Card (non-replaceable)
- 1 x 사용자 설명서
- Installation Accessories (screws, wall anchors, mounting bracket)
3. 주요 특징
- 4G LTE 연결: Operates independently without Wi-Fi, connecting via a built-in SIM card to Verizon, T-Mobile, or AT&T networks.
- 태양열 전원: Equipped with a 5W solar panel for continuous charging, ensuring wire-free and sustainable operation.
- 2K HD 해상도: 선명하고 상세한 영상을 캡처합니다.tage.
- 컬러 나이트 비전: Provides full-color night vision or infrared night vision for enhanced visibility in low-light conditions.
- 팬-틸트-줌(PTZ): Offers a 355° horizontal and 90° vertical rotation for comprehensive area coverage and 4x digital zoom.
- 스마트 모션 감지 : Features a sensitive PIR motion sensor that sends instant alerts to your smartphone upon detecting human or animal movement.
- 양방향 오디오 : 내장 마이크와 스피커를 통해 방문객과 실시간으로 소통하거나 침입자를 막을 수 있습니다.
- 원격 접속: Monitor your property from anywhere using the iCam365 mobile application.
- 유연한 스토리지: Supports local storage via an SD card (up to 128GB, not included) and optional cloud storage.
- 비바람에 견디는 디자인: IP66 rated for outdoor use, capable of withstanding various weather conditions from -10°C to 55°C (14°F to 131°F).
4. 설정 가이드
4.1 초기 충전
Before initial use, fully charge the camera for 12 hours using a standard 5V/1A or 5V/2A charger. Avoid using fast chargers, as this may damage the device or prevent proper functionality.
4.2 SIM 카드 및 SD 카드 설치
The camera comes with a built-in, non-replaceable SIM card that automatically connects to the local 4G network. It does not support third-party SIM cards. If you wish to use local storage, insert a Micro SD card (up to 128GB, not included) into the designated slot.
Figure 2: SIM Card and optional Micro SD Card slot.
4.3 앱 다운로드 및 연결
- 다운로드 아이캠365 app from your smartphone's app store (Android or iOS).
- 계정을 만들고 로그인합니다.
- Ensure the camera is powered on (check the power switch at the bottom of the camera).
- Follow the in-app instructions to add your device. The app will guide you through connecting the camera via Bluetooth.
- 연결되면 기기 이름을 지정하고 초기 설정을 구성할 수 있습니다.
4.4 카메라 및 태양광 패널 장착
Use the provided installation accessories to securely mount the camera and solar panel. Choose a location that offers optimal sunlight exposure for the solar panel and a clear view for the camera. The solar panel can be angled to maximize sun absorption.
그림 3: 예amp카메라와 태양광 패널 설치.
5. 사용 설명서
5.1 원격 모니터링 및 실시간 View
Access the iCam365 app on your smartphone to view 라이브 푸tage from your camera anytime, anywhere, using 4G data. The app provides controls for pan, tilt, and digital zoom functions.
5.2 동작 감지 및 알림
The integrated PIR motion sensor detects movement and sends immediate alert notifications to your phone. You can adjust the sensitivity settings within the iCam365 app to minimize false alarms.
Figure 4: Motion detection alert on smartphone.
5.3 야간 투시경
The camera automatically switches to night vision mode in low-light conditions. You can choose between full-color night vision or infrared night vision for optimal clarity.
Figure 5: Night vision capabilities of the camera.
5.4 양방향 오디오
Utilize the two-way audio feature through the app to speak and listen remotely. This allows for direct communication with individuals near the camera.
그림 6: 양방향 오디오 기능.
5.5 비디오 저장
녹화된 푸tage can be saved to a Micro SD card (not included) or uploaded to the optional cloud storage service. Review and manage recordings directly from the iCam365 app.
6. Data Plan Information
The KKB G200 camera operates exclusively with its pre-installed SIM card. It includes 300MB of free trial data for initial use. To continue service, you must subscribe to a data plan directly through the iCam365 app. Available plans include:
- $14.9/월
- $79.9/6 months
- 149.9달러/년
These plans offer unlimited data usage during the subscription period. The camera does not support third-party SIM cards.
Figure 7: KKB Cellular Data Plan options.
7. 유지관리
7.1 충전 팁
Always use a standard 5V/1A or 5V/2A charger for charging the camera. Using fast chargers may cause damage to the device.
7.2 내후성
The camera is IP66 waterproof, designed to operate effectively in various outdoor conditions. Its operating temperature range is from -10°C to 55°C (14°F to 131°F).
그림 8: 모든 기상 조건에서 사용 가능한 IP66 방수 등급.
7.3 청소
카메라 렌즈와 태양 전지 패널을 부드러운 천으로 주기적으로 청소하십시오.amp cloth to ensure optimal performance and clear image capture. Avoid abrasive cleaners.
8. 문제 해결
- Camera not turning on/dying at night: Ensure the solar panel is positioned to receive maximum direct sunlight throughout the day. Verify the initial 12-hour charge was completed. Check battery status in the app.
- 네트워크 연결 없음: Confirm the camera is powered on. Check the data plan status in the iCam365 app. Ensure the camera is in an area with adequate 4G LTE signal coverage.
- 알림을 받지 못했습니다: Check notification settings within the iCam365 app and your smartphone's system settings. Ensure the camera has an active data plan.
- 비디오 품질이 좋지 않음: Ensure the camera lens is clean. Check the network signal strength. Adjust video resolution settings in the app if necessary.
- 양방향 오디오 문제: Check volume settings on your smartphone and within the app. Ensure there are no obstructions blocking the microphone or speaker on the camera.
9. 기술 사양
| 특징 | 사양 |
|---|---|
| 모델 번호 | G200 |
| 연결 기술 | Wireless (Cellular 4G LTE) |
| 전원 | 태양광 발전 (5W 태양광 패널) |
| 비디오 캡처 해상도 | 2K |
| 나이트 비전 | 컬러 야간 투시경, 적외선 야간 투시경 |
| 팬/틸트 범위 | 355° 수평, 90° 수직 |
| 디지털 줌 | 4x |
| 동작 감지 | PIR 모션 센서 |
| 오디오 | 2-Way Audio (Built-in Microphone & Speaker) |
| 저장 옵션 | Micro SD 카드(최대 128GB, 포함되지 않음), 클라우드 스토리지 |
| 앱 호환성 | iCam365 (Android, iOS) |
| 방수 레벨 | IP66 |
| 작동 온도 | -10°C ~ 55°C(14°F ~ 131°F) |
| 배터리 | 리튬 이온 배터리 4개(포함) |
| 치수 | 3.7 x 5.9 x 5.6 인치 |
| 품목 무게 | 2.35파운드 |
10. 보증 및 지원
For any issues or questions, KKB offers multi-channel service including in-app online contact and email support. 7x24 hours professional technical support is available to assist you.
Figure 9: KKB Customer Support.
