VAKOLE VT4 20-inch Folding Electric Bike User Manual

소개

This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your VAKOLE VT4 folding electric bike. Please read this manual thoroughly before your first ride and keep it for future reference. Proper understanding and adherence to these instructions will ensure a safe and enjoyable riding experience.

안전 정보

여러분의 안전이 최우선입니다. 다음 지침을 항상 준수하십시오.

• 헬멧을 쓰다: 라이딩 시 항상 승인된 자전거 헬멧을 착용하십시오.
• 주행 전 점검: Before each ride, inspect brakes, tires, battery, and all quick-release mechanisms to ensure they are secure and functioning correctly.
• 교통법규: 모든 지역 교통 법규, 규정 및 표지판을 준수하십시오.
• 시계: Use lights at night or in low-light conditions. Wear reflective clothing.
• 날씨 조건: Exercise caution when riding in wet or slippery conditions. Braking distance increases significantly.
• 중량 제한: Do not exceed the maximum recommended weight of 120 kg (264 lbs).
• No Alcohol/Drugs: Never operate the e-bike under the influence of alcohol or drugs.
• 어린이들: This e-bike is designed for adults. Do not allow children to operate it.

설치 및 초기 조립

Your VAKOLE VT4 e-bike requires some assembly before its first use. A tool kit is included to assist with this process.

1. 개봉 및 검사

Carefully remove all components from the packaging. Inspect the bike for any signs of damage during transit. Report any damage to your retailer immediately.

2. 핸들바 설치 및 조정

Insert the handlebar stem into the head tube. Ensure the handlebars are aligned with the front wheel and tighten the stem bolts securely. Adjust the handlebar height to a comfortable riding position. The adjustable handlebar is suitable for riders between 160 cm and 210 cm in height.

Image: The VAKOLE VT4 electric bike in use, showing the handlebar and seat positions.

3. 페달 설치

Identify the left (L) and right (R) pedals. The right pedal threads clockwise, and the left pedal threads counter-clockwise. Apply a small amount of grease to the threads and screw them firmly into the crank arms using the provided wrench.

이미지: 클로즈업 view of the pedals on the VAKOLE electric bike.

4. 시트포스트 조절

Insert the seat post into the frame. Adjust the seat height so that your leg has a slight bend at the knee when the pedal is at its lowest point. Secure the quick-release lever firmly. The maximum adjustment distance for the seat post is 105 cm.

이미지: 자세한 view of the adjustable seat post on the VAKOLE electric bike.

5. 배터리 설치 및 초기 충전

The 36V 13Ah battery is designed to be easily removable for charging. Insert the battery into its compartment on the frame and lock it with the provided key. Before your first ride, fully charge the battery using the included charger. Connect the charger to the battery port and then to a power outlet. The charging indicator on the charger will change when fully charged.

Image: Hands demonstrating the removal or installation of the 468Wh lithium battery from the VAKOLE VT4 e-bike frame.

6. 타이어 공기압 점검

Ensure the 20-inch fat tires are inflated to the recommended pressure, typically found on the tire sidewall. Proper tire pressure is crucial for safety, performance, and battery range.

작동 지침

1. 전원 켜기/끄기 및 화면 표시

To power on the e-bike, press and hold the power button on the digital display. The display will illuminate, showing speed, battery level, and assistance mode. To power off, press and hold the power button again.

Image: A rider on the VAKOLE VT4 e-bike, with an inset showing a close-up of the LCD display.

2. Riding Modes and Pedal Assist

The VAKOLE VT4 features 3 riding modes and a professional 7-speed manual gearbox. You can switch between pedal-assist levels using the controls on the handlebar. The 250W rear hub motor provides assistance up to 25 km/h, making inclines of 15-25° easy to climb. In assisted mode (PAS-1), the bike can achieve a range of up to 75 km on a single charge.

• 페달 지원 모드(PAS): The motor provides assistance as you pedal. There are multiple levels of assistance to choose from.
• 스로틀 모드(해당되는 경우): Some models may include a throttle for motor-only propulsion. Refer to local regulations regarding throttle use.
• 수동 모드: 모터의 도움 없이 일반 자전거처럼 타세요.

3. 기어 변속

Use the 7-speed manual gearbox to select appropriate gears for different terrains and speeds. Shift gears smoothly to maintain an efficient pedaling cadence and reduce strain on the motor and drivetrain.

4. 제동

The VT4 is equipped with disc brakes for reliable stopping power. Apply both front and rear brakes simultaneously for effective and controlled braking. Practice braking in a safe area to familiarize yourself with the bike's stopping characteristics.

이미지: 자세한 view of the front wheel, disc brake, and suspension fork of the VAKOLE VT4 e-bike.

5. 접기 및 보관

The VAKOLE VT4 is a folding e-bike, making it compact for storage and transport. To fold, follow these general steps (specific mechanisms may vary slightly):

1. 안장 기둥을 완전히 낮추세요.
2. 핸들바를 접으세요.
3. Engage the main frame folding latch and fold the frame in half.
4. Fold the pedals (if applicable).

When folded, the dimensions are approximately 87 x 44 x 72 cm, allowing it to fit into a car trunk or small storage spaces.

Image: The VAKOLE VT4 e-bike in its folded state, with approximate dimensions (87cm, 44cm, 72cm) indicated.

Image: A person loading a folded VAKOLE VT4 electric bike into the trunk of a silver hatchback car, demonstrating its portability.

유지

정기적인 유지관리는 전자자전거의 수명과 안전한 작동을 보장합니다.

• 배터리 관리 :
  • 배터리의 성능을 유지하려면 사용하지 않더라도 정기적으로 충전하세요.
  • 배터리를 완전히 소모하지 마십시오.
  • 배터리는 직사광선과 극한의 온도를 피해 서늘하고 건조한 곳에 보관하세요.
  • 제공된 정품 충전기만 사용하십시오.
• 타이어:
  • 매번 주행 전에 타이어 공기압을 점검하십시오.
  • 타이어에 마모, 절단 또는 이물질이 박혀 있는지 검사하세요.
• 브레이크:
  • 정기적으로 브레이크 패드의 마모 여부를 점검하고 필요한 경우 교체하세요.
  • 브레이크 레버가 단단하고 반응이 빠른지 확인하십시오. 필요한 경우 케이블 장력을 조정하십시오.
• 체인 및 구동계:
  • 체인을 깨끗하게 유지하고 윤활유를 발라 녹이 스는 것을 방지하고 부드러운 변속을 보장하십시오.
  • 기어와 변속기가 제대로 정렬되어 있고 제대로 작동하는지 검사합니다.
• 일반 청소:
  • d로 자전거를 청소하세요amp 천과 순한 비누로 세척하세요. 특히 전기 부품 근처는 고압 세척을 피하세요.
  • 전기 부품을 물에 담그지 마십시오.

문제 해결

이 섹션에서는 VAKOLE VT4 전기 자전거를 사용하면서 발생할 수 있는 일반적인 문제에 대해 설명합니다.

명세서

보증 정보

The VAKOLE VT4 electric bike comes with a 1년 보증 from the date of purchase. This warranty covers manufacturing defects in materials and workmanship. It does not cover damage due to misuse, accidents, normal wear and tear, or unauthorized modifications. Please retain your proof of purchase for warranty claims.

고객 지원

For technical assistance, warranty claims, or any questions regarding your VAKOLE VT4 e-bike, please contact our customer support team:

• 이메일: support@vakole.com
• Web대지: www.vakole.com/support
• Please have your model number (VT4) and proof of purchase ready when contacting support.
